AC-PLC-1X32MT7-03B-CC

Category: Splitters: PLC Metal Tube

Description: 1X32 PLC Splitter W/Metal Tube No Input Connector G657A 900um SC/APC Pigtail 1m

Comparable to OEM #: N/A

Features

Axiom single-mode Planar Lightwave Circuit (PLC) Splitters are based on silica glass waveguide to provide a low cost, light distribution solution with a small form factor and high reliability. Axiom steel tube PLC splitters offer high performance in terms of low insertion loss, low PDL, high return loss and excellent uniformity over a wide wavelength range from 1260nm to 1650nm. The PLC Optical Splitters have standard configurations of 1x2, 1x4, 1x8, 1x16, 1x32, and 1x64 configurations, as well as customized configurations.

Features
• Compact design
• Low insertion loss and low PDL
• High reliability
• High channel counts
• Wide wavelength range
• Large operating temperature range from -40°C to +80°C
• Customized packaging and configuration applications
• FTTx Systems
• LAN, WAN and Metro Networks
• Analog/Digital Passive Optical Networks
• CATV Networks

Specifications Warranty

Specifications

Channel Number: 1×32
Operating Wavelength: 1260 ~ 1650 nm
Test Wavelength: 1310/1550 nm
Insertion Loss: =16.9 dB
PDL: =0.3 dB
Uniformity: =0.6 dB
Return Loss: =55 dB
Directivity: =55 dB
Fiber Type: G657A
Pigtail Type: 900µm loose tube
Fiber Length: 1m
Input Connector: None
Output Connector: SC/APC
Dimension: 80(L) × 20(W) × 6(H) mm
Operation Temperature -40 ~ +85°C
Storage Temperature -40 ~ +85°C

Warranty

3 Year Limited Warranty
